Wavelength 1 (Stokes 1) : 1034 nm
Wavelength 2 (Stokes 2) : 1025 nm
Wavelength 3 (Pump – Signal) : 740 nm … 990 nm
∆v Pump – Stokes : 350 cm-1 … 3800 cm-1
Power Stokes 1 : >300 mW (unmodulated), >150 mW modulated (20 MHz)
Power Stokes 2 : >300 mW (unmodulated), >150 mW modulated (13 MHz)
Power Pump (Signal) : >400 mW at 800 nm
Spectral bandwidth : 10 cm-1 … 15 cm-1 (Pump and Stokes)
Pulse width : 1 ps
Repetition rate : 80 MHz
Noise : Shot noise limited (-162 dBc/Hz) >1 MHz for Pump and Stokes
Beam parameters
Pointing stability : <100 µrad per 100 nm
M² : <1.2 for Pump and Stokes
Ellipticity : <20%
Polarization : Linear, horizontal >100 : 1
Beam divergence : 0.9 mrad ± 0.2 mrad at 800 nm and Stokes
Beam waist diameter : 1.3 mm ± 0.2 mm at 800 nm, 1.7 mm ± 0.2 mm for Stokes
Additional femtosecond output
Wavelength : 1030 nm ± 3 nm
Power : 300 mW
Pulse width : <200 fs
Beam divergence : <1.5 mrad
Features
Integrated modulator for Stokes : Built-in EOMs with resonant fixed frequency of 20 MHz and 13 MHz
Power attenuators : Integrated for Pump and Stokes, independent for each beam
Delay management : Automated compensation for microscope dispersion
Connectivity : Ethernet and Software interface TCP/IP
